50×50mm PCB Screen Printer , A5 Automatic Solder Paste Printer

Model Number : A5

Place of Origin : China

MOQ : 1pcs

Payment Terms : T/T,Western Union,Paypal,Credit card

Supply Ability : 5000

Delivery Time : 5-8 days

Packaging Details : 1.Wooden case and vacuum package 2.As your requirements

Price : Negotiable

Product name : SMT CNSMT-A5 Automatic Solder Paste Printer

Type : SMT PCB Solder Paste Printer

Brand : Right TECH

Condition : Used/New

PCB Min Size : 50×50mm

Transport Height : 900±40mm

Squeegee Angel : 60°/55°/45°

Warranty : 1 Year

package : wooden case

Delivery : ups,dhl,fedex,as your order

Contact Now

SMT Full Automatic Solder Paste Printer A5 Manufactuer With clean stencil system

We deeply make sure to provide you the best price and wonderful technique service, whether you are in China mainland or Asia or Europe or America countries, wenzhan always provide the best smt printer for you.

Product Specification:

Product name SMT Full Automatic Solder Paste Printer
Type SMT PCB Solder Paste Printer
Brand Right TECH
Model A5
Place of Origin China
Condition Used
Stable Mark point recognition.
Manually adjust platform
With clean stencil system

Model			A5
Item
Screen Frames		Min Size	470*370mm
		Max Size	737*737mm
		Thickness	25~40mm
PCB Min Size			50*50mm
PCB Max Size			400*340mm
PCB Thickness			0.4~6mm
PCB Warpage			<1%
Transport Height			900±40mm
Transport Direction			Left-Right;Right-Left;Left-Left;Right-Right
Transport Speed			Max 1500mm/s(Programmable)
PCB The positioning	Support System		Magnetic Pin/Up-down table adjusted/support block

Printer Head			Two independent motorised printhead
Squeegee Speed			6~200mm/sec
Squeegee Pressure			0~15kg
Squeegee Angel			60°/55°/45°
Squeegee Type			Stainless steel(standard),plastic
Stencil Separation Speed			0.1~20mm/sec (Programmable)
Cleaning System			Dry ,Wet,Vacuum (Programmable)
Table Adjustment Ranges			X:±10mm;Y:±10mm;θ:±2°
Machine
Repeate Position Accuracy			±0.01mm
Printing Accuracy			±0.025mm
Cycle Time			<7s(Exclude Printing & Cleaning)
Product Changeover			<5Min
Air Required			4.5~6kg/cm²
Power Input			AC:220±10%,50/60HZ1F3KW
Control Method			PC Control
Machine Dimensions			1220(L)1355(W)1500(H)mm
Machine Weight			Approx:1000kg

50×50mm PCB Screen Printer , A5 Automatic Solder Paste Printer

A5 pcb screen printer

50×50mm pcb screen printer

A5 Automatic Solder Paste Printer

50×50mm PCB Screen Printer , A5 Automatic Solder Paste Printer Images
